FEW 5m3 small oil tanker truck supplier in china

  • 1.Production name: Small fuel tanker truck
  • 2. Production model: CLW5061GJY3
  • 3. Overall dimensions (mm): 5990×1960×2400
  • 4. Wheel base (mm): 3300
  • 5. type of fuel: diesel
  • 6. Issuance standard: Euro III
  • 7. Volume: 1200Gallons or 5000L

FEW 5m3 oil tanker truck supplier in china

  





I. Vehicle Parameter

1、 model、name

CLW5061GJY3 refueling truck

2、 brand name

CLW

3、manufacturer

Hubei  Chengli  Special  Automobile  Co.,Ltd (IN CHINA)

4、 Overall dimension

5990×1960×2400 mm

5、curb weight

3365 Kg

6、 tank  volume

1200 Gals

7、Tank material

carbon steel Q235

8、 cab seats

3

9、Max speed

90 km/h

10、Transmission

5forward gear,1 reverse gear

11、brake system

Air brake

12、Approach/departure angle

18/12  °

13、front/ rear hang

1032/1658 mm

14、steering type

Left- hand drive( right-hand drive can opt)

15、cabin

 White (other colors are available), Flat, luxurious interior trim and seat, with air conditioning and power steering,forward flip。

16、Performance characteristic

A, with multiple baffle plates in the tank, the tank has the advantages of high intensity, stability, transporting safety etc.

B, Oil pump is installed to suck or discharge oil, with high suction pressure and speed.

C, Computer refueling machine is installed, with a 15 meter automatic return oil pipe and refueling gun, achieving mobile refueling fuction.

D, according to users’ needs, the tank can be designed as a single compartment or several compartments to contain different oils.

E, according to users’ needs, the side or the rear of the tank can be installed 1 to 3 self-flowing valves

II. Chassis parameter

1、 Chassis model

EQ1060TJ20D3

2、 Brand name

DongFeng

3、manufacturer

DongFeng Motor  Co.,Ltd.(China second automobile group company)

4、Drive type

4 x 2

5、Wheel base

3300 mm

6、Front track base

1506 mm

7、Rear track base

1466 mm

8、Tire specification

7.00R16

9、tyre number

6+1(spare tyre)

10、axle load

2595/3900 kg

11、axle number

2

III. Engine parameter

1、engine type(emission/power)

CY4102-C3F (3856 ml / 70kw )

2、 Engine manufacturer

Dongfeng Chaoyang Diesel Engine Co.,Ltd.

3、Fuel type

Diesel

4、Emissions standards

Euro3






















1. Q: How long is the warranty period?

   A: All of our trucks have one year warranty or 25000KM since you get the truck.

 2. Q: What’s the main market of yourcompany?

   A: We have customers all over the worldand our main market it Afrian, all the individuals and units are my partnerswho have a demand of china’s high quality automobile industry product.

3.  Q: How much the production capacity and supply capacity of your factory for one year?

 .  A: This depends on your needs. 10 years of spare parts sales experience makes us have a smooth supply channels.

4.  Q: Where is your factory located?

   A:Our company is located in Suizhou City,Hubei Province,the Capital of Special Purpose Vehicle in China.Warmly welcome to our factory.

5.  Q: The reason why you chose our company?

   A: We have the abundant resources supply, professional quality inspection engineers,excellent service team, we will integrate all resources for your needs, let you experience the more cost-effective and more convenient "one-stop" procurement services, effectively reduce the purchasing cost.
