Dongfeng brand (DLK) 5cbm road sweeper truck price

Dongfeng brand (DLK) 5cbm road sweeper truck price

  • 1.Production name: Road sweeper truck
  • 2.Production model: HCQ5081TSLDFA
  • 3.Overall dimensions(mm): 7160×2200×2750
  • 4.Trash tank volume (m³): 5
  • 5.Water tank volume (m³): 2
  • 5.Wheel base(mm): 3800
  • 6.Fuel Type: Diesel
  • 7.Emission standard: Euro IV
  • 8.Model of auxiliary engine: JX493G
  • 9.Sweeping speed (km / h):3-20
  • 10.Sweeping capacity(㎡/h):9000- 60000

Dongfeng brand (DLK) 5cbm road sweeper truck price




Main specifications

Product model、name

HCQ5081TSLDFA   Road Sweeper Truck

Gross weight(Kg)

8275

Drive type

4 X 2

Payload (Kg)

2100

Overall dimension (mm)

7160×2200×2750

Curb weight(Kg)

5980

cab seats (man)

3

Approach / departure angle(°)

24/12

Front/rear hang(mm)

1210/2150

Number of axles

2

Wheelbase(mm)

3800

Axle load

3310/4965

Max speed(Km/h)

95

Chassis specifications

Chassis model

DFA1080SJ12D3

Manufacturer

DongFeng  Motors Co., Ltd.

Brand name

DongFeng

Overall dimension(mm)

6815×2080×2440

Tire specification

7.50R16

Tires No.

6

Steel spring number

8/10+7,11/9+7

Front track(mm)

1770

 Fuel type

Diesel

Rear track(mm)

1586

Emission standard

Euro IV

Transmission

5 forward gear,1 reverse gear

Cabin

Car interiors, with the direction of power and USB interface, cassette player, with air conditioning,

Engine model

Engine manufacture

Displacement(ml)

Power(Kw)

CY4102-CE4C

DongFeng Chaoyang Diesel Co.,Ltd

3856

91

Road Sweeper Performance

Trash tank volume (m³)

5

Water tank volume (m³)

2

Material of trash tank

Stainless steel

Material of water tank

Stainless steel

Model of auxiliary engine

JX493G

Power of auxiliary engine(Kw)

57KW

Manufacturers of auxiliary engine

JiangXi ISUZU Engine Co., Ltd.

Max sweeping width(mm)

3200

Sweeping speed (km / h)

3-20

Sweeping capacity(㎡/h)

9000- 60000

Maximum Grain size and quality (mm)

100mm\±1.5kg

Cleaning Rate

96%































1. Q: How long is the warranty period?

   A: All of our trucks have one year warranty or 25000KM since you get the truck.

 2. Q: What’s the main market of yourcompany?

   A: We have customers all over the worldand our main market it Afrian, all the individuals and units are my partnerswho have a demand of china’s high quality automobile industry product.

3.  Q: How much the production capacity and supply capacity of your factory for one year?

 .  A: This depends on your needs. 10 years of spare parts sales experience makes us have a smooth supply channels.

4.  Q: Where is your factory located?

   A:Our company is located in Suizhou City,Hubei Province,the Capital of Special Purpose Vehicle in China.Warmly welcome to our factory.

5.  Q: The reason why you chose our company?

   A: We have the abundant resources supply, professional quality inspection engineers,excellent service team, we will integrate all resources for your needs, let you experience the more cost-effective and more convenient "one-stop" procurement services, effectively reduce the purchasing cost.
