3 TONS ISUZU 4x2 refrigerator van supplier for sale3 TONS ISUZU 4x2 refrigerator van supplier for sale3 TONS ISUZU 4x2 refrigerator van supplier for sale3 TONS ISUZU 4x2 refrigerator van supplier for sale3 TONS ISUZU 4x2 refrigerator van supplier for sale

3 TONS ISUZU 4x2 refrigerator van supplier for sale

  • 1. Production name: Freezer
  • 2. Production model: CLW5054JGKZ3
  • 3. Dimensions (mm): 7400 × 1980 × 3100
  • 5.Wheel base (mm): 3360
  • 6. Fuel type: diesel
  • 7. Emission standards: Euro IV

3Tons ISUZU 4x2 Refrigerator van supplier for sale






Main specifications

Product model and name

CLW5040XLCQ4 refrigerator truck

Gross weight (Kg)

4475

Drive type

4×2

Quality (kg)

1495

Dimensions (mm)

5995×1910×2790

Curing weight (Kg)

2850

Cab seat

2

Approach/departure angle (°)

24/16

Front/rear suspension (mm)

One thousand six hundred and twenty-one thousand one thousand and fifteen

Axle number

2

Wheelbase (mm)

3360

Axle load (Kg)

1800 of 2675

Maximum speed (Km / h)

98

Chassis specification

Chassis model

QL10403HARY

Manufacturer

Qingling Motor Co., Ltd.

Brand

ISUZU

Size (mm)

5900×1860×2180

Tire specifications

7.00-15

Tire number

6

Number of steel springs

8/6 + 5

Front track base (mm)

1385

Gasoline type

diesel engine

Rear track base (mm)

1425

Emission Standards

Euro 4

transmission

5 forward gear, 1 reverse gear

taxi

Single row, air conditioning, power steering, USB and radio

Engine information

engine model

4JB1CN

Engine manufacturer

Qingling Isuzu Engine Co., Ltd.

Displacement (ml) / power (kW)

2771/98 (98hp)

Max Torque

220 N.m.

Max Torque speed

3400 rpm

performance

Van body size (mm)

4100×1740×1750

Load capacity (TON)

3

Minimum cooling temperature (°C)

-18 degrees Celsius

Features and applications

Refrigerator trucks are enclosed vans used to transport frozen or fresh goods. The truck consists of a vehicle chassis, a polyurethane insulated car, a refrigeration unit and a temperature recorder. It is commonly used to transport frozen foods, dairy products, vegetables and fruits, and vaccines. Special requirements for trucks such as meat transport, meat hooks, aluminum rails and ventilation slots can be selected and installed.































1. Q: How long is the warranty period?

   A: All of our trucks have one year warranty or 25000KM since you get the truck.

 2. Q: What’s the main market of yourcompany?

   A: We have customers all over the worldand our main market it Afrian, all the individuals and units are my partnerswho have a demand of china’s high quality automobile industry product.

3.  Q: How much the production capacity and supply capacity of your factory for one year?

 .  A: This depends on your needs. 10 years of spare parts sales experience makes us have a smooth supply channels.

4.  Q: Where is your factory located?

   A:Our company is located in Suizhou City,Hubei Province,the Capital of Special Purpose Vehicle in China.Warmly welcome to our factory.

5.  Q: The reason why you chose our company?

   A: We have the abundant resources supply, professional quality inspection engineers,excellent service team, we will integrate all resources for your needs, let you experience the more cost-effective and more convenient "one-stop" procurement services, effectively reduce the purchasing cost.
