New style China mobile kitchen truck factoryNew style China mobile kitchen truck factoryNew style China mobile kitchen truck factory

New style China mobile kitchen truck factory

  • 1.Production name: Mobile Food Truck
  • 2.Production model: CA4DC3-10E5
  • 3.Overall dimensions(mm): 5740*1920*2890
  • 4.Cabinet size(mm) (mm): 4200x1800x1850
  • 5.Wheel base(mm): 3300
  • 6.Fuel Type: Diesel
  • 7.Emission standard: Euro V
  • 8.Gearbox: 5 forward gears and 1reverse gears
  • 9. Left hand drive

New style China mobile kitchen truck factory


MOBILESALES SHOP



Manufacture's direct selling in order to save costs for our customers



Keep a good quality and create a good comfortable outdoor sales window








Vehicle information

Production name

Engine model

Rated power (kW/rpm)

Max net power (kW/rpm)

Rated torque (N.m/rpm)

displacement(L)

Emission standard

Engine type

Max speed Km/h

Mobile food truck

CA4DC3-10E5

79/3200

76/3200

245/20000

3.0

V

Turbocharged intercooler

High pressure common rail

100

Basic specification



Length(mm)

5740

Fuel consumption (L/100km)

15.0

Width(mm)

1920

Braking distance (v=30km/h)

≤10

High(mm)

2890

Maximum gradient (%)

30

Carriage height

1800

Minimum turning diameter (m)

≤15

Wheelbase

3300

curb weight (kg)

Vehicle

4090,4150,4220,4350

Front/rear suspension (mm)

940/1500

Front / rear axle

1650/2440,1680/2470,1710/2510,1760/2590

Track before after (mm)

1606/1430

Maximum mass (kg)

Vehicle

4480

Minimum ground clearance (mm)

150

Front / rear axle

1820/2660

Approach angle / departure angle (°)

24/13

Engine position

Front

Program

Standard configuration

Optional configuration



Clutch

Single piece dry, hydraulically operated remotely



Transmission

Domestic five speed gearbox



front axle

Lean to axle, carrying capacity 2.2t



Rear axle

Lean to axle, carrying capacity 4T



suspension system

Leaves (3/4), hydraulic shock absorber



steering system

Power steering, steering wheel up and down, front and rear adjustable



braking system

Pneumatic double loop, front disc and drum brake, breathe, dryer, self adjustment arm, WABCO ABS



tyre

Triangle: 225/75R16LT, no spare wheel



Tank (gas cylinder)

70L



Frame

Bending beam



Engine thermal management system

no 





vehicle

body

match



Body structure

Semi load structure, stretch skin, front door, three steps, rear blind window, driver's rear partition (no door with dialogue window)

Fully closed tempered glass

body trim

Simplify interior trim, flat floor (wheel cover raised), imitation solid wood flooring leather, left display rack (with lamp belt and advertising lamp box), right lockers (with expansion plate)



Door and pump

Remote control type toughened glass outside swinging door (front swing) and rear single door (can be opened inside and outside)



Chair

Driver's chair, staff seat



AC

No

AC No driving air conditioner (partition installing driving zone)

Train air conditioner (whole car)

1.5P city electric top air conditioner

Warm air system

No



Defrost system

Engine residual heat defrost



Rear view system

Hand lever reverse mirror, front blind mirror



Others

The car fire extinguisher, engine room with 1 double fire bombs, no wind window, front windshield sunshade, the driver on the right side (the curtains, turn around the lamp with valgus door), back stepping and fan driver manual activities



electric

implement

match

The

Electrical system

24V, single wire, negative electrode



power supply system

120Ah storage battery (two) /70A generator (100A distribution train air conditioner)



Audiovisual system

MP3 retracting machine

Power amplifier, 1 piece, 32 inch foreign TV, roof 2 waterproof sound column



Auxiliary-parking system

No

Color reversing monitor

Vehicle lamp

Integral front lamp, split rear lamp



Service facilities

Traveling data recorder (with GPS)



Electricity Allocation

City electric access system (90Ah service battery, 1KW charging and inverting machine)



Others

Wiper





    

Standard Configuration: The food truckexternal surface body is fiberglass steel, intermediate interlayer for heatinsulation and fire insulation layer, and the internal surface is stainless steel;The left and right side and the backside can be expanded and there is vendingbar on both left and right side. The internal compartment is installed with LED floodlights, megaphone, master switch, USB interface, large space locker; Theoutside of the compartment is installed with two loudspeakers,105A  storage battery,220V external power supply interface,15m external power supply cord,telescopic truck pedal; Different truck colors and skin stickers are optional.



Food truck optional equipments description:

Optional Configuration: Internal compartment equipment can be customised according to user's requirements suchas generator/freezer/cold drink machine/vending bar/cooker etc; The left andright side of the compartment body can be chosed different structure forms ofside panel; The selling window can be also opened on any side of the truck bodyaccording to customer demand, the below board can be unfold to extend the cargoarea in vending operation; The glass sliding window can be also choosed on bothside of the compartment body.The back door of the compartment can choose singleopen door, double flat open door or lift-up door. Both sides and back of thecompartment can be optional advertising glass roller light box or LEDscreen.Truck roof can choose overhead air conditioning,baggage holder,left andright side can be chosed awning,the back side of the truck can be chosedcrawling ladder.











Summary:

· selling snacks,as a fast food cart which you can make and sell fast food

· kitchen cart which you can make food for yourself

· shop which you can sell phone card and phone

· aid post which you can help everyone

· book store which you can sell newspaper , magazine etc

· housing when you have a trip by car or jeep

· repare shop to main for your clients

· empty cart which do it by yourself



























1. Q: How long is the warranty period?

   A: All of our trucks have one year warranty or 25000KM since you get the truck.

 2. Q: What’s the main market of yourcompany?

   A: We have customers all over the worldand our main market it Afrian, all the individuals and units are my partnerswho have a demand of china’s high quality automobile industry product.

3.  Q: How much the production capacity and supply capacity of your factory for one year?

 .  A: This depends on your needs. 10 years of spare parts sales experience makes us have a smooth supply channels.

4.  Q: Where is your factory located?

   A:Our company is located in Suizhou City,Hubei Province,the Capital of Special Purpose Vehicle in China.Warmly welcome to our factory.

5.  Q: The reason why you chose our company?

   A: We have the abundant resources supply, professional quality inspection engineers,excellent service team, we will integrate all resources for your needs, let you experience the more cost-effective and more convenient "one-stop" procurement services, effectively reduce the purchasing cost.
