left hand drice concrete mixer truck left small for sale

  • 1.Production name: small concrete mixer truck
  • 2.Production model: BJ5162GJB1
  • 3. Overall dimensions (mm): 6765 × 2499 × 3420
  • 5. Base wheel (mm): 3600
  • 6. Type of fuel: Diesel
  • 7.Emission Standard: Euro III
  • 8. Engine model: YC4D130-33
  • 9.Tank volume (m3): 3-5

left hand drice concrete mixer truck left small for sale









Main specifications

Product model, name

BJ5162GJB1 concrete mixer truck

Gross weight (kg)

15990

Type of unit

4x2

Payload (Kg)

7805

Overall dimension (mm)

6765 × 2499 × 3420

Empty weight (Kg)

7990

Cabin seats (man)

3

Approach / departure angle (°)

29/43

Front / rear suspension (mm)

1190/1975

Number of axes

2

Distance between axes (mm)

3600

Axle load (Kg)

5995/9995

Maximum speed (Km / h)

80

Chassis specifications

Chassis model

BJ1162V5PDB-E1

Manufacture

Beijing Foton Daimler Automotive Co., Ltd.

Name of the brand

Photon

Total dimension (mm)

6190 × 2300 × 2600

Specification of the tire

9.00-20 (16PR)

Tires No.

6

Steel spring number

9/11 + 9

Front track (mm)

1790

Fuel type

Diesel

Back track (mm)

1725

Issuance standard

Euro III

Transmission

5 marches forward

Engine information

Engine model

Yc4d130-33

Engine manufacturer

Guangxi Yuchai Machinery Co., Ltd ..

Displacement (ml)

4214

Power (kw)

96

Max Torque

420 N.m

Speed ​​in Max Torque

2800 rpm

Performance truck mixer

Tank volume (m3)

4

Tank material

Q345

Bomb

Made in China

Motor

Made in China

Reducer

Made in China

Surplus ratio

≤1.0%

Volume of the water tank (L)

150L

The water method supplied.

Tire

Characteristics of the concrete mixer truck

This is mainly used for modern roads and major construction projects, which is to ensure the quality of the poured concrete by shaking the concrete slowly and continuously during transport or at the construction site.




















1. Q: How long is the warranty period?

   A: All our trucks have a one year warranty or 25000KM since you got the truck.

 2. Q: What is the main market of your company?

   A: We have customers all over the world and our main market is Afrian, all individuals and units are my partners that have a demand for high quality automotive products from China.

3. Q: How much the production capacity and supply capacity of your Factory for one year?

 . A: This depends on your needs. 10 years of experience in the sale of spare parts make us have a supply channel without problems.

4. Q: Where is your factory located?

   A: Our company is located in the city of Suizhou, Hubei Province, the capital of the special purpose vehicle in China. Welcome to our factory.

5. Q: The reason why you chose our company?

   A: We have abundant supply of resources, professional quality inspection engineers, excellent service team, we will integrate all the resources for your needs, we will allow you to experience the most profitable and convenient all-in-one procurement services to effectively reduce the purchases. cost.
